Ecutek with SD tune passing NY emissions?


  • Please log in to reply
14 replies to this topic

#1 XViper

XViper

    R32 Member

  • Members
  • PipPip
  • 203 posts

Posted 05 February 2016 - 07:48 PM

Is it possible to legitimately pass Nys emissions with a SD tune? The SD tune is supposedly smoother than a MAF tune. I'm new to all this so please go easy on me. Thanks in advance.

2015 Black Edition SS GTR

4.1L HKS 1000+

Shep 1k Transmission

Fore Triple 12 injector Setup [ID 1000cc primary / ID 2000cc secondary]

E85 Flex Fuel


#2 droptopp

droptopp

    NISMO Member

  • Members
  • PipPipPipPipPipPipPip
  • 8668 posts

Posted 05 February 2016 - 11:18 PM

Definitely not on Cobb. Need to run through MAF sensors as pass through. Probably sand on Ecutek.

What's your setup ?
If your just FBO stay on MAF, don't see any advantage.

Edited by droptopp, 05 February 2016 - 11:18 PM.

TSM Billet Crank 4.1 w/ CP billet pistons, TSM Elite Prime turbos, TSM Wet Sump Oling upgrade, flex fuel, ETS mid and down pipe, STM titanium axle back, STM race FMIC, ID2000s, Shep One K with drop gears and all the goodies., DS Axles, Volk Saga 18 10/12 (MT ET Streets), Advan GT Premium 20 R888. 1450+ hp / 1210+ tq

Old setups : Alpha 9 w/ AMS 3.8, GTX3582R Gen II w/ AMS 4.1 billet crank, GTX3582R Gen II w/ AMS 4.0 big bore billet crank and of course FBO E85.

#3 Dan_585

Dan_585

    R34 Member

  • Members
  • PipPipPipPip
  • 1568 posts

Posted 05 February 2016 - 11:22 PM

Definitely not on Cobb. Need to run through MAF sensors as pass through. Probably sand on Ecutek.

What's your setup ?
If your just FBO stay on MAF, don't see any advantage.

STM said they would only tune with an SD kit on mine. Are you running it or MAF?

Not trying to have an issue passing emissions.

Sent from my SM-G920V using Tapatalk


MK6 GTI 3xxwhp 4xxwtq

2500HD SLT 4x4 Duramax 6" lift, 4xxwhp 9xxwtq


#4 Urban

Urban

    Turbo AWD or Nothing

  • NAGTROC Certified Member
  • PipPipPipPip
  • 1223 posts
  • Location:New York

Posted 05 February 2016 - 11:27 PM

Definitely not on Cobb. Need to run through MAF sensors as pass through. Probably sand on Ecutek.

What's your setup ?
If your just FBO stay on MAF, don't see any advantage.


Im currently FBO on a SD tune with cobb and i pass nys emissions. Had my tuner make me a MAF map and running o2 fowlers. When the time comes i swap to the MAF map and baby the car to inspection. Pass then swap maps. No problems.

05 Subaru WRX STi - 04 Porsche 996 TT Cab (Sold) - 93 GMC Typhoon (Sold) - 2011 Triumph Daytona 675
2012 GT-R Deep Blue Pearl BE Alpha 10x
Instagram: UrbanGTR

#5 XViper

XViper

    R32 Member

  • Members
  • PipPip
  • 203 posts

Posted 05 February 2016 - 11:35 PM

My tuner also prefers SD tune. I just don't want issues with emissions. It's just fbo with flex fuel. I'm trying to see if anyone actually got it to pass with an SD tune on ecutek.

Sent from my SM-N910T using GT-R Life mobile app


2015 Black Edition SS GTR

4.1L HKS 1000+

Shep 1k Transmission

Fore Triple 12 injector Setup [ID 1000cc primary / ID 2000cc secondary]

E85 Flex Fuel


#6 droptopp

droptopp

    NISMO Member

  • Members
  • PipPipPipPipPipPipPip
  • 8668 posts

Posted 05 February 2016 - 11:57 PM

STM said they would only tune with an SD kit on mine. Are you running it or MAF?

Not trying to have an issue passing emissions.

Sent from my SM-G920V using Tapatalk


Surprised, no need for SD on FBO E85, I passed NYS inspection easy on MAF. My problem with the A9 is I don't have MAF sensors I can use as a pass through for inspection only.

Khary's was on MAF and ran 9.9's @ 138 and also passed inspection.
TSM Billet Crank 4.1 w/ CP billet pistons, TSM Elite Prime turbos, TSM Wet Sump Oling upgrade, flex fuel, ETS mid and down pipe, STM titanium axle back, STM race FMIC, ID2000s, Shep One K with drop gears and all the goodies., DS Axles, Volk Saga 18 10/12 (MT ET Streets), Advan GT Premium 20 R888. 1450+ hp / 1210+ tq

Old setups : Alpha 9 w/ AMS 3.8, GTX3582R Gen II w/ AMS 4.1 billet crank, GTX3582R Gen II w/ AMS 4.0 big bore billet crank and of course FBO E85.

#7 XViper

XViper

    R32 Member

  • Members
  • PipPip
  • 203 posts

Posted 06 February 2016 - 12:27 AM

Thanks guys. I'll stay on maf for now until I build. I'll tell my tuner to use maf. SD is beneficial for bigger builds right?

Sent from my SM-N910T using GT-R Life mobile app


2015 Black Edition SS GTR

4.1L HKS 1000+

Shep 1k Transmission

Fore Triple 12 injector Setup [ID 1000cc primary / ID 2000cc secondary]

E85 Flex Fuel


#8 Dan_585

Dan_585

    R34 Member

  • Members
  • PipPipPipPip
  • 1568 posts

Posted 06 February 2016 - 02:23 AM



Surprised, no need for SD on FBO E85, I passed NYS inspection easy on MAF. My problem with the A9 is I don't have MAF sensors I can use as a pass through for inspection only.

Khary's was on MAF and ran 9.9's @ 138 and also passed inspection.


Sent emery an email. Might sell my SD kit if thats the case. Not sure why he told me SD only.

Sent from my SM-G920V using Tapatalk


MK6 GTI 3xxwhp 4xxwtq

2500HD SLT 4x4 Duramax 6" lift, 4xxwhp 9xxwtq


#9 dLad

dLad

    R.I.P. Paul Walker

  • NAGTROC Certified Member
  • PipPipPipPipPipPipPip
  • 7535 posts
  • Location:NY

Posted 06 February 2016 - 03:35 AM

I think SD kit helps hold boost better to redline. In other words, once boost hits it's peak..it doesn't taper off as much. Correct me if I'm wrong.

Sent from my Galaxy S5 using GT-R Life mobile app



Edited by dLad, 06 February 2016 - 03:36 AM.

White (Now Blue Chrome Wrapped) 2013 GTR
10.890 @ 122.11mph (stock)


#10 [email protected]

[email protected]

    R35 Member

  • Members
  • PipPipPipPipPip
  • 2978 posts
  • Location:Wallingford, CT / Seattle, WA

Posted 06 February 2016 - 07:39 AM

I think SD kit helps hold boost better to redline. In other words, once boost hits it's peak..it doesn't taper off as much. Correct me if I'm wrong.

Sent from my Galaxy S5 using GT-R Life mobile app

No. the purpose of the SD kit is to relocate the intake air temperature sensor to post-charge/intercooler which allows for more accurate representation of the temp at the throttle bodies. A side effect of this is that it simplifies the tuning process because airflow is adjusted via 1 table (the volumetric efficiency table) as opposed to a combination of several to correctly represent the MAF and pipe size characteristics.

Other benefits of SD include the ability to run Vent-To-Atmosphere BOVs without issue as the volume of air is accounted for, and also if you blow an intercooler pipe the car will run normally in vacuum, whereas on MAF it won't.

Edited by Bullitt 2496, 06 February 2016 - 07:41 AM.

Weapons Grade Performance
- Cobb Protuner / EcuTek Master Tuner / MoTec Calibrator
[email protected]
Our Online Store
East Coast Location Durham, CT - West Coast Location Monroe, WA

#11 Visconti

Visconti

    NISMO Member

  • Members
  • PipPipPipPipPipPipPip
  • 5224 posts
  • Location:CT & NY

Posted 06 February 2016 - 09:18 AM

If you still have the Mafs plugged in on Ecutek you should pass.

I've had several people tell me that recently they passed NY inspection

#12 XViper

XViper

    R32 Member

  • Members
  • PipPip
  • 203 posts

Posted 06 February 2016 - 09:31 AM

This is exactly what I heard people tell me as well. I want to pass emissions with a SD tune. SD tune cars tend to be smoother or maybe it's just my imagination.

Sent from my SM-N910T using GT-R Life mobile app


2015 Black Edition SS GTR

4.1L HKS 1000+

Shep 1k Transmission

Fore Triple 12 injector Setup [ID 1000cc primary / ID 2000cc secondary]

E85 Flex Fuel


#13 [email protected]

[email protected]

    R35 Member

  • Members
  • PipPipPipPipPip
  • 2978 posts
  • Location:Wallingford, CT / Seattle, WA

Posted 06 February 2016 - 09:52 AM

This is exactly what I heard people tell me as well. I want to pass emissions with a SD tune. SD tune cars tend to be smoother or maybe it's just my imagination.

Sent from my SM-N910T using GT-R Life mobile app

They definitely can be, assuming the tuner takes the time to make sure the VE table is smooth in the drivability areas.

MAF tunes also suffer on drivability when the airflow is erratic, such as when the car has a big cam or in transitional areas such as tip in or quick liftoff and re-throttle, when the cooling fans kick on or off, or when the piping design creates turbulence.

I remember back in the day my Evo 8 with a big HKS suction open intake would stall at a stop light if something big revved it's engine next to me haha.

For a bit of legalese... On the subject of emissions passing... people need to remember that products like aftermarket tunes, downpipes, etc are installed for off-road use and the responsibility to pass emissions with these modifications is your own. I've been to shops where the tuners refuse to disable codes, etc., to protect themselves from the significant liability an EPA inspection could bring.

On another note, depending on your local criteria for readiness testing quantity pass/fail, the presence of flex fuel can also cause a fail because it typically disables the secondary air injection monitor.

Most of the Cobb cars that I've seen fail are typically because the injector settings aren't quite perfect and long term fuel trims aren't working as well as they should (or at all), which is a criteria for test readiness, and/or the tests won't ready if the injector scalar is over 1000cc.

Edited by Bullitt 2496, 06 February 2016 - 09:54 AM.

Weapons Grade Performance
- Cobb Protuner / EcuTek Master Tuner / MoTec Calibrator
[email protected]
Our Online Store
East Coast Location Durham, CT - West Coast Location Monroe, WA

#14 stormyboy

stormyboy

    R33 Member

  • Supporter
  • PipPipPip
  • 581 posts
  • Location:Windsor, ONT

Posted 01 May 2016 - 08:33 AM

Im currently FBO on a SD tune with cobb and i pass nys emissions. Had my tuner make me a MAF map and running o2 fowlers. When the time comes i swap to the MAF map and baby the car to inspection. Pass then swap maps. No problems.


Reviving thread... this is good info right here -- thanks! Did a quick check with my scanner for readiness after I got my car home from Switzer (SD tuned) and saw that I had 3 not ready.
2010 Pearl White P800 GT-R 708whp/619lb.ft
2014 F-150 Crew Cab XTR 4x4 Ecoboost (daily driver)
2015 BSM X5d M-Sport pkg (wife's)
2007 Alpine White M6 convertible (wife's)
2007 Ducati 1098s
2014 BMW HP4 Competition
2017 Yamaha R1M

#15 JDMFairlady21

JDMFairlady21

    R32 Member

  • Members
  • PipPip
  • 143 posts

Posted 03 May 2016 - 10:58 AM

Doug's last post hit it right on the head. Touche on those points
